A recent GCN (no, not that one) got me poking around at inGraphs trying to satisfy my curiosity. While I was doing so I stumbled across this:
This is an inGraph of ProcessCPUTime, which according to the docs is “the CPU time used by the process on which the Java virtual machine is running in nanoseconds.” Leaving aside the bit where it gets all wibbly-wobbly (that would be the GCN) notice how those lines are nice and tight up until just after 07: 00, when they diverge. Another look at this phenomenon in a different fabric:
So under “low” load the amount of CPU time each process gets is pretty much the same, but as load increases/goes past a certain threshold some processes get more CPU time than others. Interesting.
My theory for this was that perhaps the respective machines on which these services are running have different CPUs; under load, perhaps a service running on a “faster” processor gets more CPU time as compared to a service running on a “slower” processor. So…how to go about vetting this out? I don’t have access to the machines (I don’t own this service), so inspecting /proc/cpuinfo directly is a no-go. Hmmm…
I asked around a bit and Jamie Henderson_ put me on the right path: inQuery. After fumbling with the interface a bit I came up with this query:_
inquery facts –range “%prod-lor1.accessTokens-midtier.1” –fact-list “processors.count,processors.speed”
Which produced the following result:
…and there you have it - some of the nodes have more processors with a faster clock speed.
Satisfied that I’d proved out my theory, my curiosity turned to the query itself. It’s got the look-and-feel of a CLI, yeah? So I dropped it into my terminal and, lo and behold!
{ “data”: [ { “hostname”: “lor1-app10811.prod.linkedin.com”, “processors.count”: 24, “processors.speed”: “3.30 GHz” }, { “hostname”: “lor1-app1519.prod.linkedin.com”, “processors.speed”: “3.30 GHz”, “processors.count”: 24 }, { “hostname”: “lor1-app16992.prod.linkedin.com”, “processors.count”: 24, “processors.speed”: “3.30 GHz” }, { “hostname”: “lor1-app30448.prod.linkedin.com”, “processors.count”: 24, “processors.speed”: “3.30 GHz” }, { “hostname”: “lor1-app33455.prod.linkedin.com”, “processors.count”: 24, “processors.speed”: “3.30 GHz” }, { “hostname”: “lor1-app34460.prod.linkedin.com”, “processors.count”: 24, “processors.speed”: “3.30 GHz” }, { “hostname”: “lor1-app34787.prod.linkedin.com”, “processors.speed”: “3.30 GHz”, “processors.count”: 24 }, { “hostname”: “lor1-app35215.prod.linkedin.com”, “processors.count”: 24, “processors.speed”: “3.30 GHz” }, { “hostname”: “lor1-app35606.prod.linkedin.com”, “processors.count”: 24, “processors.speed”: “3.30 GHz” }, { “hostname”: “lor1-app35918.prod.linkedin.com”, “processors.count”: 32, “processors.speed”: “3.70 GHz” } ], “total”: 16, “offset”: 0, “limit”: 10, “elapsed_time”: 93.9946 }
Neat!
